Appendix A: Modular network card compatibility
Table 9: Duplex Fiber Media Cards Modular Network Card compatibility
4100-6301, 4100-6302, 4100-6303, 4100-6304 Duplex Fiber Media Cards Modular Network Card Compatibility
Part # PID Description Compatible
4100/4100U/4100ES
566-793 4100-6014 / 4100-6078 4100/4100ES SMT 2D Modular Network Card Yes
566-793 4100-9863/ 4100-9864 4100/4100ES SMT TCP/IP Physical Bridge Card Yes
566-794 4100-6101/ 4100-6102
4100-6036/ 4100-6037
4100/4100ES SMT Modem Physical Bridge Card
(a 566-793 card with Physical Bridge firmware)
Yes
565-649 4100-6023/ 4100-6024
4120-6023/ 4120-6024
4100/4120 2D Modem Physical Bridge Card
(a 565-516 card with Physical Bridge firmware)
No
565-516 4100-9849/ 4100-9850 4100/4120 TCP/IP 2D Modular Physical Bridge Card No
565-516 4100/4120 2D Modular Network Card No
565-409 4100 1D Modular Network Card No
565-245
4100-6014
4120-6014/ 4120-0149
4100 Modular Network Card No
4010ES
566-850 4010-9922 4010ES SMT Modular Network Card Yes
566-851 4010-9903/ 4010-9904
4010-9924/ 4010-9925
4010ES SMT Modem Physical Bridge Card Yes
566-857 4010-9926/ 4010-9927 4010ES TCP /IP Physical Bridge Card Yes
4007ES
566-1192 4007-9810 4007ES SMT Modular Network Card (Flat) Yes
4020
566-826 N/A 4020 SMT 2D Modular Network Card Yes
566-827 N/A 4020 SMT Modem Physical Bridge Card Yes
565-518 4020 2D Modular Network Card Yes
565-411 4020 1D Modular Network Card No
565-277
4020-6014
4020 Modular Network Card No
565-650 4020-6023 4020 Modem Physical Bridge Card
(a 565-518 card with Physical Bridge firmware)
Yes
4002
566-825 N/A 4002 SMT 2D Modular Network Card Yes
565-519 4002 2D Modular Network Card Yes
565-432
4002-6012
4002 1D Modular Network Card No
NSI
566-829 4190-9830/ 4190-9831 Network System Integrator Yes
566-729 4190-9826/ 4190-9827 Network System Integrator (Old) Yes
IMS/TSW
746-208 4190-6033/ 4190-6061 TSW PCI Modular Network Card Yes
655-272 IMS/TSW PCI Modular Network Card No
655-222
4190-9821/ 4190-9829
IMS/TSW PCI Modular Network Card No
GCC/NPU
565-695 GCC/NPU ISA Modular Network Card (short card) No
565-202
4190-6031
GCC/NPU ISA Modular Network Card (long card) No
4010
566-807 4010 SMT Modular Network Card (Rev-C and later) Yes
566-807 4010 SMT Modular Network Card (Rev-B and earlier) No
565-818
4010-9817
4010 SMT Modular Network Card No
579-182 Rev. V
© 2019 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision and are subject to change without notice. Additional listings may be applicable, contact your local Autocall
product supplier for the latest status. Listings and approvals under Tyco Fire & Security GmbH, and the product names listed in this material are marks and/or registered marks. Unauthorized use is strictly prohibited. NFPA 72 and National
Fire Alarm Code are registered trademarks of the National Fire Protection Association (NFPA).
