Simplex 4100U Instruction Manual

5 S4100-0036-4 10/2003
Model Description Details and Mounting Reference
4100-1243
Master Microphone Module; one maximum
per audio system; mounts on front panel
Requires 2 Slots (4” [102 mm]), locate on expansion bay only; space behind
for 4100U flat modules only Supv. current = 2.4 mA; Active current = 6 mA
4100-1252 1 Channel (audio or mike)
4100-1253 1.5 Channel (audio + mike)
4100-1254 2 Channel (full audio)
4100-1255 3-8 Channel
Operator
Interface
Modules
Single slot modules requiring connection to an LED/switch controller (see
page 9); space behind controller accepts 4100U flat modules only
Additional adjacent LED/switch module(s) are required for specific speaker
circuit selection
Firefighter Telephone System Products (refer to S4100-0034 for additional detail)
Model Description Details and Mounting Reference
4100-1270
Master Telephone with Telephone Control
Module and 3 Class B telephone NACs; for
Fire Alarm Control Panels
One max. per audio system; front panel module; space behind for 4100U flat
modules only; telephone control module mounts on bay module mounting
plate; use LED/switch modules for circuit control
4100-1272 Telephone Module with 3 phone NACs Class B NACs, single Block module, mounts to bay mounting plate
4100-1273 Telephone Class A Adapter Module Mounts to 4100-1272, no additional space required
Analog Emergency Voice/Alarm Communications Equipment, Constant Supervision Compatible*
Model Description Details
4100-9620
Basic Analog Audio Operation with microphone, requires
dedicated expansion bay
Includes: Expansion Bay, 4100-1210 Analog Controller Board,
Microphone Module, and Audio Expansion Bay Kit
4100-1210
Analog Controller Board only; order expansion bay and
audio expansion bay kit separately
Controller board mounts in Blocks A and B
4100-1361 25 VRMS output NAC rating = 1.4 A
4100-1362 70.07 VRMS output
Flex-35, 35 W Amplifier,
constant supervision compatible
NAC rating = 0.5 A
35 W, or 100
speakers
4100-1312 25 VRMS output NAC rating = 2 A
4100-1313 70.7 VRMS output
Flex-50, 50 W Amplifier,
constant supervision compatible
Includes three on-board
Class B audio NACs;
power is supplied from an
XPS, RPS, or SPS
NAC rating = 0.707 A
50 W, or 100
speakers
100 W Analog Amplifiers with Power Supply, Constant Supervision Compatible
Model/Output Voltage
25 VRMS 70.7 VRMS
Power Supply Input/Listing Description Details
4100-1314 4100-1315 120 VAC, 60 Hz UL
4100-1316
4100-1317
120 VAC, 60 Hz ULC
4100-1318
4100-1319
220/230/240 VAC, 50/60 Hz UL
Primary
100 W
Amplifier
Includes six, Class B audio NACs;
NAC rating = 50 W or 100 speakers
maximum; 2 A @ 25 VRMS;
1.4 A @ 70.7 VRMS
4100-1320
4100-1321
120 VAC, 60 Hz UL
4100-1322
4100-1323
120 VAC, 60 Hz ULC
4100-1324
4100-1325
220/230/240 VAC, 50/60 Hz UL
Backup
100 W
Amplifier
Uses the six Class B NACs of primary
amplifier
ULC
models
have low
battery
dropout
circuit
Digital Emergency Voice/Alarm Communications Equipment*
Model Description Details
4100-9621
Basic Digital Audio Operation with microphone, requires
dedicated expansion bay
Includes: Expansion Bay, 4100-1311 Digital Controller Board,
Microphone Module, and Audio Expansion Bay Kit
4100-1311
Eight Channel Digital Controller Board only; order
expansion bay and audio expansion bay kit separately
Controller board mounts in Blocks A and B
4100-1363 25 VRMS output NAC rating = 1.4 A
4100-1364 70.07 VRMS output
Flex-35, 35 W Amplifier,
constant supervision compatible
NAC rating = 0.5 A
35 W, or 100
speakers
4100-1326 25 VRMS output NAC rating = 2 A
4100-1327 70.7 VRMS output
Flex-50, 50 W Amplifier,
constant supervision compatible
Includes three on-board
Class B audio NACs;
power is supplied from an
XPS, RPS, or SPS
NAC rating = 0.707 A
50 W, or 100
speakers
100 W Digital Amplifiers with Power Supply, Constant Supervision Compatible
Model/Output Voltage
25 VRMS 70.7 VRMS
Power Supply Input/Listing Description Details
4100-1328 4100-1329 120 VAC, 60 Hz UL
4100-1330 4100-1331 120 VAC, 60 Hz ULC
4100-1332 4100-1333 220/230/240 VAC, 50/60 Hz UL
Primary
100 W
Amplifier
Includes six, Class B audio NACs;
NAC rating = 50 W or 100 speakers
maximum; 2 A @ 25 VRMS;
1.4 A @ 70.7 VRMS
4100-1334 4100-1335 120 VAC, 60 Hz UL
4100-1336 4100-1337 120 VAC, 60 Hz ULC
4100-1338 4100-1339 220/230/240 VAC, 50/60 Hz UL
Backup
100 W
Amplifier
Uses the six Class B NACs of primary
amplifier
ULC
models
have low
battery
dropout
circuit
Options for use with either Analog or Digital Amplifiers*
Model Description Model Description
4100-1245
Flex-35/50 NAC Expansion Module; (Adds 3
Class B, 1.5 A NACs)
4100-1248
100 W Amplifier NAC Expansion Module; (Adds six
Class B, 2 A NACs)
4100-1246
Flex-35/50 Class A Adapter for 3 NACs
4100-1249
100 W Amplifier Class A Adapter Module for 6 NACs
* Refer to document S4100-0034 for additional audio module information. Continued on next page
NDU with VCC, Emergency Voice/Alarm Communications Selection*

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
