6 S4100-0036-4 10/2003
LED/Switch Modules, General Purpose (LED/switch controller and label kit is ordered separately)
Model LEDs per Switch LED Color(s) LED Quantity Switch Quantity
4100-1276 Red; pluggable 8
4100-1277
LEDs only
Red on top, Yellow on bottom, pluggable 16
LEDs only
4100-1280 One Red
4100-1281 One Yellow
8
4100-1282 Two Red on top, Yellow on bottom
4100-1283 Two Yellow, top and bottom
4100-1284 Two Red on top, Green on bottom
4100-1296 Two Green on top, Yellow on bottom
16
8
4100-1285 One Red
4100-1278 One 8 Red on left, 8 Yellow on right
16 16
4100-1287 One Red 24 24
LED/Switch Modules, Special Purpose (LED/switch controller and label kit is ordered separately)
Model Operation
4100-1286 Eight function HOA (On, Off, Auto) Control Module with labeled switches; ON/OFF/Auto; Green/Red/Green LEDs
4100-1295 Eight function HOA (On, Off, Auto) Control Module, same as 4100-1286 except switches are unlabeled
LED/Switch Controller Modules and Accessories (LED kits for 4100-1276/1277 are on page 7)
Model Description
4100-1288
64 LED/64 Switch Controller Module with mounting plate; controls up to 64 LEDs and
interfaces to up to 64 switches; mounts behind the LED/switch modules and has
provisions for one 4100-1289 Controller Module
4100-1289
64 LED/64 Switch Controller Module without mounting plate; mounts on extra space of
4100-1288; controls an additional 64 LEDs and 64 switches
NOTE: LED/switch controllers and
their connected LED/switch
modules must be in the same bay.
4100-1294 LED/Switch Module Slide-in Labels, required when LED/switch modules are present; order one per cabinet
Model Color Model Color Model Color Description
4100-9843 Yellow 4100-9844 Green 4100-9845 Red Kits of 8 LEDs; order as required for 4100-1276/1277 modules
Model Voltage/Listing Description Size Supv. Alarm
4100-5101 120 VAC UL
4100-5103 120 VAC, Canadian ULC
4100-5102 220-240 VAC UL
Expansion Power Supply (XPS); 9 A output, 3 built-in 3 A
Class A/B NACs that can provide synchronized strobe or
SmartSync™, two-wire operation
2
Blocks
50 mA 50 mA
4100-5115 NAC Expansion Module, 3 NACs, Class A/B, mounts on XPS only N.A. 25 mA 25 mA
4100-5111 120 VAC UL
4100-5112 120 VAC, Canadian ULC
4100-5113 220-240 VAC UL
Additional System Power Supply (SPS); 9 A power
supply/charger with 250 point IDNet channel, 3 Class A/B
NACs, and expansion slot for City Circuit or Alarm Relay
option; Canadian model has low battery cutout
4
Blocks
175 mA 225 mA
4100-5125 120 VAC UL
4100-5126 120 VAC, Canadian ULC
4100-5127 220/230/240 VAC UL
Remote Power Supply (RPS); 9 A power supply with battery
charger for up to 50 Ah batteries; 3 built-in Class A/B NACs,
same as in XPS
4
Blocks
150 mA 185 mA
4100-5120 120 VAC UL
4100-5121 120 VAC, Canadian ULC
4100-5122 220-240 VAC UL
TrueAlert
®
Power Supply (TPS); 3 Class B SLCs rated 3 A
each for up to 63 TrueAlert addressable appliances per
channel, 189 per TPS; built-in battery charger; 2 A aux. power
output; add device current separately, 0.2 mA standby (see
S4009-0003 for additional detail)
4
Blocks
88 mA 100 mA
4100-5124 TrueAlert SLC Class A Adapter for all 3 SLCs, mounts on TPS only N.A. 7 mA 7 mA
4100-5152 12 VDC Power Option, 2 A @ 12 VDC maximum 1 Block 1.5 A maximum
4100-0634 120 VAC
4100-0635 220/230/240 VAC
Power Distribution Module (PDM); select per system voltage;
one required per box or cabinet rack
Options for either Analog or Digital Systems (refer to data sheet S4100-0034 for additional module details)
Model Description Model Description
4100-1259 Constant Supervision Adapter for 25 VRMS Amplifiers 4100-5116 Expansion Signal Module; three, 1.5 A NACs
4100-1260 Constant Supervision Adapter for 70.7 VRMS Amplifiers 4100-1266 NAC Extender
4100-1240 Auxiliary Audio Input Module; four additional inputs 4100-1267 Class A Adapter
4100-1241 8 Minute Message Expansion Module 4100-1268 Constant Supervision Adapter
Options for use with
Expansion Signal
Module
4100-1242 32 Minute Message Expansion Module 4081-9018 End-of-line resistor for 70.7 VRMS NACs; 10 k:, 1 W
NDU with VCC, Emergency Voice/Alarm Communications Selection (Continued)
NDU with VCC, LED/Switch Modules (refer to S4100-0032 for additional detail)
Expansion, Remote, and TrueAlert Power Supplies and Accessories for NDU with VCC
