Operating Instructions - 18
IV-F. OPERATING INSTRUCTIONS - AFC Controller
1. Connect a truck ground cable from the truck to the provided ground stud.
2. Connect the delivery hose from the truck to the hose coupling at the unit.
3. On Smartpump/Mini-Smartpump units, open both inlet/outlet isolation valves.
3-a. On multi-tank Fuelports, verify the manual ball valve is open.
3-b. Smartpump ONLY, open air purge valve until air has been purged from system and then
close valve.
4. Turn the Fill Controller power switch to the ON position.
5. Select the appropriate tank to be filled on the touch screen.
6. If equipped with a Bypass feature, verify the switch is in the proper position. Use "By-pass" for
trucks equipped WITH a pump or "On-Board" for trucks WITHOUT a pump.
7. Open valve on truck.
8. Press "Start Fill" button on the touch screen or F1 if applicable.
9. Wait for fill valve to completely open, if applicable.
10. On Smartpump/Mini-Smartpump units, the on-board pump will start automatically.
10a. FuelPort units, start the truck pump
11. Delivery may be stopped at any time by pressing the "Stop Fill" button on the touch screen or F2
if applicable.
12. When the "Tank Full" level is reached, an indication will be displayed, the alarm horn will sound,
the fill valve will close, and/or the on-board pump will stop, if applicable.
13. Filling may continue in 30 second increments by pressing the "Hose Drain" button, or F1 if
applicable.
14. Stop the pump on the truck, if applicable.
15. If filling more than 1 tank, return to step 5.
16. If the "Tank High" level is reached, an indication will be displayed, the horn will sound, the valve
will close, and/or the on-board pump will stop, if applicable. The selected tank will be locked out
from any further filling operation until the level drops below the high level.
17. If any tank in the system should reach the "Critical High" level, all valves and any pumps will be
locked out until the critical high has cleared. (Multi-tank system only)
18. When filling operations are complete, return to the Main Screen.
19. On Smartpump/Mini-Smartpump units, close both inlet/outlet isolation valves.
20. Disconnect the delivery hose.
21. Turn the Fill Controller power switch to the OFF position.
22. Close and lock the fill unit.
23. Disconnect the truck ground cable.
These are abstracted instructions. Please refer
to your fill controller section for details.
