3
The following general temperature/humidity specifications apply to the SafeLINC FPII card.
The equipment operates normally with ambient temperatures outside the cabinet from 32° to
120° F (0° to 49° C), inclusive.
The equipment operates normally under non-condensing humidity conditions up to 93% relative
humidity at 90° F (32° C).
Effective Operating Temperature Range ……. 32° to 120° F (0° C to 49° C), assuming 41° F
(5° C) rise in FACP cabinet.
Effective Operating Humidity Range ……….. 10 to 93% relative humidity (±2%)
non-condensing at 90° F (32° C) (±2°).
SafeLINC FPII power is supplied from system FACP 24 V. On-board power supplies include
5 V, 3.3 V, and 2.5 V with each supply powered from the 24 V FACP connection.
Maximum Battery Standby Current Draw ….. 115 mA Maximum on 24 V rail (Worst Case).
SafeLINC FPII Card Specifications
General
Temperature/Humidity
Requirements
Specific
Temperature/Humidity
Requirements
Power Requirements
