10 - 3
10 Transmission Removal & Installation
Tuff Torq K-56 Models
Ref. Qty. Description
1 4 NUT, Flange Whiz-Lock, 5/16-18
2 1 JAM NUT, Top Lock, 5/16-18
3 1 ANCHOR, Torsion Bar, L.H.
4 4 SCREW, Flange, Whiz-Lock, 5/16-18 x 2-1/2
5 1 SCREW, Taptite, 5/16-18 x 3-1/2
6 1 SCREW, Taptite, 5/16-18 x 3
7 2 SCREW, Taptite, 5/16-18 x 2-1/2
8 1 SCREW, Hex,Whiz-Lock, 5/16-18 x 1-1/4
9 1 LOCK NUT, Flange, 5/16-18
10 1 TORSION BAR
11 1 ANCHOR, Torsion Bar, R.H.
12 1 TRANSMISSION ASSY, Tuff Torq K-56
13 3 SCREW, TAPTITE, 1/4-20 x 1-1/2
14 1 FAN
15 2 SET SCREW, Brass Tipped
16 1 PULLEY ASSY
17 1 RETAINING RING
18 1 CAPSCREW, 5/16-18 x 1
19 2 NUT, Flange, 1/2-13, 2-Way Lock
20 1 SPACER
21 3 WASHER, 1/2
22 2 CAPSCREW, 1/2-13 x 1-1/2
23 1 BUSHING
24 1 BELT GUIDE
25 2 WASHER, 11/32 x 3/4 x 1/16
26 1 SCREW, Taptite, 5/16-18 x 3/4
27 1 NUT, 5/16-18
28 1 LOCKWASHER, 5/16
29 1 BELT, Drive
30 1 ROD, Transmission Release
31 1 COTTER PIN
32 1 LOCKNUT, Center, 1/4-20
33 1 LOCKNUT, Flange, 1/4-20
34 1 SPACER
35 1 LOCKNUT, Flange, 1/4-20
36 1 SPACER
37 1 BRAKE ARM (Part of Carrier Assembly)
38 1 BRAKE LINK
39 1 CAPSCREW, 1/-20 x 1
40 1 LOCKNUT, Flange, 5/16-18
41 1 SPACER
42 1 ROD, Transmission Control
43 1 STUD, Shock Mounting
44 1 SHOCK ABSORBER
Transmission & Carrier Assembly - Tuff Torq K-56 Models
