7 Electrical System Service
Troubleshooting Flow Chart
7 - 18
Check all wires and connec-
tions.
Refer to
A. Check / Clean
Wires and Connectors.
Replace damaged wires
or connectors.
Component Tests OK
Component
Fails Test
Check the the key switch. Refer to
E. Key Switch
Tests.
Replace the key switch.
Component Tests OK
Component
Fails Test
Check the PTO switch. Refer to
F. PTO Switch
Test.
Replace the PTO switch.
Component Tests OK
Component
Fails Test
Check the grey pedal
switch.
Refer to
G. Foot Pedal
Switch Tests.
Replace the pedal
switch.
Component Tests OK
Component
Fails Test
Check the seat switch. Refer to
I. Seat Switch Test.
Replace the seat switch.
Component Tests OK
Component
Fails Test
Check the engine ignition
system.
Refer to the Engine Manual. Replace defective com-
ponents.
Done
Component
Fails Test
Check the key switch. Refer to
E. Key Switch
Tests.
Replace the key switch.
Component Tests OK
Component
Fails Test
Check the fuel solenoid. Refer to
N. Fuel Solenoid
Test.
Replace the fuel sole-
noid.
Done
Component
Fails Test
Engine will turn over but will not start:
Engine runs for a few seconds then dies:
To Next Page
