Simplicity Regent Hydro-Gear 0650 Series

7 - 19
7 Electrical System Service
Troubleshooting Flow Chart
Check the grey pedal
switch.
Refer to G. Foot Pedal
Switch Tests.
Replace the foot pedal
switch.
Component Tests OK
Component
Fails Test
Check the seat switch. Refer to I. Seat Switch Test. Replace the seat switch.
Done
Component
Fails Test
Check the PTO switch. Refer to F. PTO Switch
Test.
Replace the PTO switch.
Component Tests OK
Component
Fails Test
Check the PTO switch. Refer to F. PTO Switch
Test.
Replace the PTO switch.
Component Tests OK
Component
Fails Test
Check the seat switch. Refer to I. Seat Switch Test. Replace the seat switch.
Done
Component
Fails Test
Engine dies when brake pedal released:
Engine dies when PTO engaged:
PTO clutch will not engage:
Check the key switch. Refer to E. Key Switch
Tests.
Replace the key switch.
Component Tests OK
Component
Fails Test
Check the PTO clutch. Refer to K. PTO Clutch. Replace the PTO clutch
assemble.
Done
Component
Fails Test
