071807 VI. Figures
32
CARPET
FLOOR
ON
OFF
White
White
White
White
Red
Black
Black
Black
Handle
Harness
Power
Cord
NOTE: Light “ON” in switches on handle only indicates
that there is power to the switches.
The lights will come on any time the power cord is
plugged into an outlet and the switch is turned “ON”
regardless of whether the handle is installed in the
vacuum.
Q. Handle Wiring
