071807 I. Common Issues
5
C.3. Identifying Models by PCB Layout or Belt Idler Assembly
Figure B. PCB Layout and Belt Idler Assembly
Belt Idler Assembly Belt Idler Assembly
PC Board PC Board
.5 and .6 .4 and older
Brush Roll AFI
Fuse
NOTE: The PC Boards in the .5 and .6 do not have adjustment pods because they have a hall sensor on the belt idler assembly.
