B. Appliance Preparation
Removing Front Finishing Trim:
To remove the front nishing trim, remove the two (2) Phil-
lips screws located at the top of the trim. See Figure 4.2.
With the screws removed pull the friction t trim straight
out and away from the appliance.
Glass Removal:
To remove the front viewing glass, remove the screws at-
taching the glass retaining bracket to the appliance. See
Figure 4.3.
With the retaining bracket removed from the appliance,
use the provided suction cup to pull the glass forward.
Do not rely on the suction cup for lifting of the glass!
See Figure 4.4.
Carefully tilt the glass forward and lift it out of the bottom
channel and away from the appliance. See Figure 4.4.
Set glass aside by placing one edge on a soft surface.
Interior Side Panel Removal:
To access the appliance mounting holes, the interior side
panels must be removed.
Remove the left and right interior side panels by removing
the two (2) screws attaching them to the appliance ceil-
ing. Use the small tab located on the top of each panel to
pull the top downward and away from the appliance side-
wall. The panel’s bottom tab will lift out of the appliance.
Repeat for both sides. See Figure 4.5.
REMOVE 2 PHILLIPS SCREWS
FOR FRONT REMOVAL
Figure 4.2 Front Removal
REMOVE PHILLIP SCREWS ATTACHING
GLASS RETAINING BRACKET
Figure 4.3 Remove Glass Retaining Bracket
Figure 4.4 Tilt and Remove Glass
REMOVE 2
PHILLIP SCREWS
PULL TAB AWAY FROM
APPLIANCE SIDEWALL
Figure 4.5 Side Panel Removal
