SimPure T1 - Page 10

• Install the feed water adaptor valve
The SimPure
®
T1 Water Purification system requires a connection to the
water supply. To do this, we use the supplied feedwater adaptor.
Tip:
When applying
Teflon thread tape,
always wrap the tape
in the same direction
‘
clockwise’ as if you
were tightening the
fitting.
Warning: Make sure you have turned
the water supply off.
Unscrew the cold
-water connection with the
adjustable wench
Wrap a
couple of turns of Teflon tape around
all the male threads. Connect the cold
-water
supply and feed water adapter.
Optional Fittings:
The feed water
adaptor valve is provided with ½” NPT
t
hreads, if your installation requires ⅜” compression
threads then utilize the
two additional reducing
bushes
in your kit.
Note: Please disregard the two ½” x
⅜” bushes if
not
required for your installation.
• Water Pressure Tank Assembly
The SimPure
®
T1 Water Purification system comes complete with a
water pressure tank to allow for a smooth and continuous output flow.
Wrap the threaded tank stem with Teflon
tape and screw the valve onto the top of the
tank
hand-tight only; do not use any tools.
Only lightly tighten this fitting, the
Teflon tape will make the seal
without being over-tightened.
Place the Water
Pressure Tank onto the
stand to secure the tank. You may notice an
air valve connection on the side of the tank;
this sets the internal bladder pressure and
has been factory set. Please do not adjust.
Need assistance?
Contact SimPure!
Web: www.simpurewater.com
eMail: info@simpurewater.com
Toll-Free Phone: +1-866-528-4572
15 16
Optional:
⅜” compression
thread
Optional:
⅜” compression
thread
½"NPT
thread
½"NPT
thread
