System conguration | AP70/AP80 Installation Manual
Conguring the drive system
The drive system configuration is accessed from the drive system configuration dialog.
1. Select the drive to be configured, and press the rotary knob or the MENU key to proceed to
the device information dialog
2. Enter a descriptive name for the device (e.g. Aft thruster)
- If two identical boards are used, they are identified by the serial number. This number is
found in the device information dialog on a tag on the SimNet plug on the board
¼ Note: The label below is an example only and varies with board type.
AD80
AD80
3. Select the Configure option to proceed to device configuration dialog. The dialog differs
slightly for the different drive types
4. Select relevant settings for the selected drive, and save your settings
