Drawings |
AP70/AP80 Installation manual
A
C70 and SI80 C
omputer
211 mm (8.29")
197 mm (7.77")
185 mm (7.27")
60 mm
(2.36")
180 mm
(7.08")
80 mm
(3.15")
48 mm
(1.88")
SD80 and AD80 C
omputers
211 mm (8.29")
197 mm (7.77")
185 mm (7.27")
60 mm
(2.36")
167 mm
(6.58")
80 mm
(3.15")
48 mm
(1.88")
80
82
