Specications | AP70/AP80 Installation manual
Autopilot Computers
¼ Note: For signal specification of the board(s), see “Computer boards” on page 74.
SI80, AC70, AD80 and SD80 computers
SI80 AC70 AD80 SD80
Board
SI80 board x
AC70 board x
AD80 board x
SD80 board x
POWER
Local supply
12/24 V DC, +30 - 10%.
Need 12 V CAN supply
N/A N/A
Consumption local
supply
0,3 - 5 A
CAN bus load
dependent
100/65 mA
at 12/24 V
DC + load of
connected
equipment
(motor,
solenoids,
clutch etc.)
N/A N/A
NMEA 2000 Load
Equivalent number
(50 mA)
1 1 4 3
Output for CAN bus
supply
15 V DC,
+/- 5%, 4 A
max
N/A N/A N/A
ENVIRONMENT
Temperature, operation -15°C to +55°C (5°F to 131°F)
Temperature, storage -30°C to +70°C (-22°F to 158°F)
Protection IPx2
MECHANICAL
Weight 0,9 kg (2 lbs) 1 kg (2.2 lbs) 0,5 kg (1.1 lbs)
Size (length x width x
height)
See “AC70 and SI80 Computer”
on page 81
See “SD80 and AD80
Computers” on page 81
Mounting Bulkhead
Compass safe distance 1 m
Material
Plastic front and anodized
aluminum back
Plastic
Color Black
Cable inlet
Slots:
9 x 95 mm and 18 x 45 mm
(0.4” x 3.7” and 0.7” x 1.8”)
