22 | BSM-2 Installation manual
Manufacturer Model Description
Frequency
(KHz)
Balance
load
TAP (Ref
page 14)
Airmar
Narrow
Band
B744
Bronze Thru Hull 50/200Khz Depth/Temp/
Speed w 45/12˚ Beamwidths and high Speed
Fairing Block.
12 m (39.4 ft) cable
50 300ohms E
200 340ohms C
B164
Bronze Low Prole Thru Hull 1kW 50/200Khz
Depth/Temp w 22/20˚ 6/6˚ Array Beamwidths
and 12˚ tilt.
12 m (39.4 ft) cable
50 240ohms E
200 180ohms B
B258
Bronze Thru Hull 50/200Khz Depth/Temp
w 15/21˚ 3/5˚ Array Beamwidths and High
Speed Fairing Block.
12 m (39.4 ft) cable
50 225ohms E
200 200ohms B
B260
Bronze Thru Hull 50/200Khz Depth/Temp w
19/6˚ Beamwidths and High Speed Fairing
Block.
12 m (39.4 ft) cable
50 250ohms E
200 90ohms A
B260
(Diplexer)
Bronze Thru Hull 50/200Khz Depth/Temp w
19/6˚ Beamwidths and High Speed Fairing
Block. Depth/Temp
12 m (39.4 ft) cable
50 250ohms E
200 310ohms B
