BSM-2 Installation manual | 23
ENGLISH
Manufacturer Model Description
Frequency
(KHz)
Balance
load
TAP (Ref
page 14)
Airmar
Broadband
B765
600W Bronze Thru Hull
40/60Khz with 20°-40° beamwidths
130/210Khz with 10°-16° beamwidths
w/HS Fairing block
Depth/Temp/Speed
12 m (39.4 ft) cable
50 (40-60) 100-250
Ohms
B
200 (130-210)
100-250
Ohms
E
B265
1kW Bronze Thru Hull
40/60Khz with 21°-31° beamwidths
130/210Khz with 6°-10° beamwidths
w/HS Fairing block
Depth/Temp
12 m (39.4 ft) cable
50 (40-60)
100 - 400
ohms
F
200 (130-210)
90 - 250
ohms
B
R209
3kW Thru Hull
33/60Khz with 6°-11° x 11°-17° beamwidths
130/210Khz with 5°-7° beamwidths
Depth/Temp
15 m (49.2 ft) cable
38 (33-60)
90 - 175
ohms
D
200 (130-210)
90 - 250
ohms
B
R299
3kW Tank Kit
33/60Khz with 6°-11° x 11°-17° beamwidths
130/210Khz with 5°-7° beamwidths
Depth only
15 m (49.2 ft) cable
38 (33-60)
90 - 175
ohms
D
200 (130-210)
90 - 250
ohms
B
