Specications | FU80, NF80, QS80 User Guide
Specications
Technical specications
¼ Note: For updated technical specifications, compliance and
certifications, refer to our websites.
Display
Display resolution 128 x 64 (H x W)
Display type 2” Monochrome, Bounded, Transflective
Viewing direction NF80: 12 o’clock
FU80/QS80: 6 o’clock
Power
Power supply Via CAN bus or SimNet
Current consumption Off: Network <20 mA (NMEA 2000: LEN 1)
On with max illumination: Network <110
mA (NMEA 2000: LEN 3)
Interface
CAN/NMEA 2000 Factory connected drop cable with
Micro-C connector. 6 m (19.7 ft)
SimNet Via optional SimNet to Micro-C cable
Technical
Housing Front: Aluminum with black plastic snap-
on bezel
Back: Plastic cover
Temperature -25° C to + 55° C (-13° F to +131° F)
Weight NF80, FU80: 0.5 kg (1.10 lbs)
QS80: 0.4 kg (0.88 lbs)
Environmental
Weather IEC 60945 sec. 8.8, exposed, front when
desk mounted or bulkhead mounted with
optional frame.
Corresponds to IP X6
Compass safe
distance
0.4 m (ref. IEC 60945 sec.11.2)
55
