14 |
Operation | FU80, NF80, QS80 User Guide
Taking command
Take command by pressing the CMD key. When command is
transferred, the autopilot system will remain in current mode.
In an open system (no command transfer restrictions), you will get
immediate control on the remote unit requesting command.
In a multi-station system with active lock function, the command
request must be confirmed on the active control unit before you
can use the remote.
CMD
Display on remote, and... on AP70/AP80
Using the NF80
The NF80 lever has a mechanical spring that will return the lever to
the mid-position when the lever is released.
You can use the NF80 in NFU, AUTO and NoDrift mode.
You can also get command if the system is in FU, NAV or Wind
mode, but you cannot operate these modes from the NF80.
Initial mode Lever moved / Resulting mode (action)
Standby
NFU (rudder command)NFU
FU
AUTO AUTO (heading change)
NoDrift NoDrift (course change)
NAV
No action (warning sound and information dialog)
Wind
¼ Note: The Wind mode is not available for AP60, AP70 or AP80
systems.
If the mode is available on other autopilot systems, the mode can
only be used if the system is set up for sailboat. See the Installation
manual for your system.
For more
information about
multi-stations, see the
Operator Manual for
your autopilot system.
