Page #16 background image
16 |
Operation | HS60 GPS Compass User Guide
PG No.
(PGN)
Description
Default
Update
Rate
(msec)
Freq.
(Hz)
129539 GNSS DOPs
Provides a single transmission contain-
ing GNSS status and dilution of precision
components (DOP) that indicate the
contribution of satellite geometry to the
overall position error. There are three DOP
parameters reported: horizontal (HDOP),
vertical (VDOP), and time (TDOP).
1000 1
129540 GNSS satellites in view
GNSS information on current satellites in
view tagged by sequence ID. Information
includes PRN, elevation, azimuth, SNR,
defines the number of satellites; defines the
satellite number and the information.
1000 1
129542 GNSS pseudorange noise statistics
GNSS pseudorange measurement noise
statistics can be translated in the position
domain in order to give statistical measures
of the quality of the position solution.
Intended for use with a Receiver Autono-
mous Integrity Monitoring (RAIM) applica-
tion.
1000 1
Single frame packet denition - PGN: EFXX (Destination ad-
dressable)
MSGIDs Description MSGIDs Description
0x0001 N2K,MCODE 0x001B JK (read)
0x0002 N2K,PCODE 0x001C File Transfer Details
0x0003 N2K,LOAD 0x001 JWCONF,12
0x0004 N2K,CERT 0x001E GNSS receiver boot
loader reply messages
0x0005 JVERSION 0x001F JI, application version
0x0006 N2K,RESET 0x0020 JSYSVER
0x0007 N2K,ADDRESS 0x0021 JT
0x0008 JDIFF 0x0022 JATT,MSEP
0x0009 JDIFF,INCLUDE 0x0023 JATT,CSEP
0x000A JMODES 0x0024 ERROR
