| 23
Installation | HS60 GPS Compass User Guide
Mounting options
The HS60 allows for both pole or flush mounting. Follow directions
below for detailed mounting directions.
Dimensions
The below illustration and on the next page illustrates the physical
dimensions of the HS60.
45.16 mm
129.48 mm
259.93 mm
H60 dimensions without adapter
129.48 mm
127.71 mm
259.93 mm
Dimensions with adapter
