Simrad HS60 User Manual

| 31
Specications | HS60 GPS Compass User Guide
Specications
Item Specication
GPS sensor specications
Receiver type GPS L1 Compass
Channels Two 12-channel, parallel tracking (Two
10-channel when tracking SBAS)
SBAS tracking 2-channel, parallel tracking
Update rate 10 Hz standard (position and heading)
Position accuracy:
Single Point
1
SBAS
2
1 m (95%)
3 m (95%)
Heading accuracy 2° (RMS)
Heave accuracy
3
< 30 cm (RMS)
Pitch/Roll accuracy 2° (RMS)
Rate of turn 90°/s maximum
Cold start < 60 s typical (no almanac or RTC)
Warm start < 20 s typical (almanac and RTC)
Hot start < 1 s typical (almanac, RTC, and position)
Heading fix < 10 s typical (valid position)
Compass safe distance 30 cm (11.8 in)
Maximum speed 1,850 kph (999 kts)
Maximum altitude 18,288 m (60,000 ft)
Communication specications
Port NMEA 2000
Data I/O protocol NMEA 2000
Power specications
Input voltage 8 to 36 VDC
Power consumption ~ 2.0 W nominal
Current consumption 165 mA @ 12 VDC
Power isolation Isolated to enclosure
Reverse polarity protec-
tion
Yes
5
