Technical specications | HS80/HS80A/MX575C/MX575D User Manual
Power
Item Specification
HS80/MX575C HS80A/MX575D
Input voltage 6 to 36 VDC
Power consumption 3 W nominal
Current consumption HS80/HS80A MX575C/MX575D
320 mA @ 9 VDC 350 mA @ 9 VDC
240 mA @ 12 VDC 265 mA @ 12 VDC
180 mA @ 16 VDC 200 mA @ 16 VDC
Power isolation Isolated to enclosure
Reverse polarity protection Yes
Mechanical
Item Specification
Enclosure UV resistant, white plastic, AES HW 600G, non-corrosive,
self-extinguishing
Dimensions 209.16 W x 668.54 L x 122.32 H (mm)
8.234 W x 26.320 L x 4.815 H (in)
Weight HS80/HS80A
2.131 kg (4.70 lb)
MX575C/MX575D
2.44 kg (5.38 lb)
Environmental
Item Specification
Operating temperature -30°C to +70°C (-22°F to +158°F)
Storage temperature -40°C to +85°C (-40°F to +185°F)
Humidity 95% non-condensing
Vibration IEC 60945
EMC FCC Part 15, Subpart B; CISPR22; IEC 60945 (CE)
Certications
Heading Device (HS80 & MX575C)
IMO Resolution MSC.116(73) ISO 22090-3 Ed.1.0, 2004 incl. Corr. 1,2005
IMO Resolution A.694(17) IEC 60945 Ed.4.0, 2002 incl. Corr.1, 2008
IMO Resolution MSC.191(79) IEC 61162-2 Ed.1.0, 1998
IEC 61162-1 Ed.4.0, 2010
IMO Wheelmarked for Annex A.1 item 4.41 Transmitting heading device THD (GNSS method.
Based on the Directive 2009/26/EC.
