3
NSO evo3S | Quick Guide - EN
Application pages
D
A
B
C
A Home/pages button
B Application panel
C Menu button
D Instrument bar
E Control bar
Adjust panel size
You can adjust the panel sizes in a split page.
1 Tap the adjust split button in the System Controls dialog to show the resize icon
2 Drag the resize icon to set preferred panel size
3 Save the changes by tapping the screen
Charts
• Zoom the chart by using spread or pinch
gestures or by using the zoom buttons.
• Move the view in any direction by panning
the chart.
• Display information about a chart item by
tapping the item.
Waypoints
To create a waypoint: select the new waypoint option in the menu.
¼ Note: With cursor inactive, the waypoint is placed at vessel’s position. With cursor
active, the waypoint is placed at selected cursor position.
