Simrad NSS evo3 Software Upgrade Instructions

| 15
Update procedure | Software upgrade instructions
9 The MFD will shutdown and then restart
Restarting
10 The installation will begin. A progress bar will be displayed. DO NOT TURN OFF OR REMOVE
POWER TO THE MFD AT THIS TIME
Installing update. Please wait...
Do not trun o during update, as
this may damage your device
11 Once the upgrade is complete the MFD will start normally.
12 Remove the media card

Simrad NSS evo3 Specifications

General

Touchscreen	Yes
NMEA 0183 Connectivity	Yes
Operating System	Linux-based
Chartplotter	Yes
Radar Support	Yes
Waterproof Rating	IPX7
Operating Temperature	-15°C to +55°C
Display Size	9, 12, 16 inches
Screen Type	LCD
GPS	10 Hz built-in GPS receiver
Networking	Ethernet, Wi-Fi, Bluetooth
Sonar	CHIRP, StructureScan
Power Supply	12V DC
Video Input	2
Card Slots	2 x MicroSD
Processor	Quad-core processor
RAM	1GB
Internal Storage	8GB
Resolution	1280 x 800 (12")
