442729/A

Result

ST90turnedoffST90turnedon

Ambienttemperature:

Relativehumidity:

Requirements

Results

ThecompartmentinwhichtheTransceiverUnitisinstalled("sonarroom")

iscleananddry.

Aventilationsystemisinstalled.

Recordthetypeofventilationsystemthatisinstalled.

Therearenocorrosiveattacks.

Dateandsignature:

MakingsurethatallST90cablesareproperly

connected

TheST90reliesoncommunicationbetweeneachsystemunit,andbetweentheST90and

externaldevices.Itisveryimportantthatallcablesarecorrectlyinstalled,thattheproper

cabletypeshavebeenused,andthatallcablesareconnectedcorrectly.

Prerequisites

TheST90isinstalledasspeciedintheST90Installationmanual.

•TheST90isturnedoff.

•Allsystemcablesareinstalled.

•Allcableconnectionsaremade.

Youneedthefollowingequipment:

•Cabletester

•Multimeter

Context

AllcablingisdescribedintheCablelayoutandinterconnectionschapterinthe

ST90InstallationManual.Refertothecableplan,thecablelistandthebasiccable

requirements.

Visualinspection
