Secondaryprocedures
TheenduserandtechnicaldocumentationfortheST90containsseveralproceduresthat
arealsoapplicableforthisHarbourAcceptanceTest.Theseproceduresarenot
partof
theHarbourAcceptanceTest.Theyareprovidedforreferencepurposesonly.Ifyou
scanacompletedHarbourAcceptanceTestforarchivingorreportingpurposes,itis
notnecessarytoincludetheseprocedures.
Topics
SettinguptheOperatingPanel(Mk2),page57
SettinguptheOperatingPanel(Mk2)
TheOperatingPaneloffersallnecessarycontrolfunctionsfornormaloperationofthe
ST90.Beforeitcanbeputtouse,theOperatingPanelmustbeconguredtopermit
EthernetcommunicationbetweenthepanelandtheProcessorUnit.
Prerequisites
TheOperatingPanelisinstalledasspeciedintheST90Installationmanual.TheST90
ProcessorUnitisturnedon.
Thefollowingspecicitemsarerequiredforthistask.
•Computermouse
•Computerkeyboard
Neithertoolsnorinstrumentsarerequired.
Context
Whensupplied,theOperatingPanelissetupwiththefollowingcommunication
parameters:
•IPAddress:157.237.60.20
•Subnetmask:255.255.255.0
•Gateway:157.237.60.1
Secondaryprocedures
