442729/A

Result

Requirements

Results

Themaximumnumberofunserviceableelementsis3.

Dateandsignature:

Furtherrequirements

Ifthenoiselevelishigherthanspecied,youmustcheckthereason(s)forthis.

•CheckthegroundingoftheTransceiverUnit.

•Verifythatotherelectricequipmentand/ormachineryonboard,suchascooling

systems,hydraulicpumps,electricmotorsetc,donotinuenceonthenoisereading.

Switchoffasmuchmachineryaspossible,especiallyelectricalmotors.

•Checkforinterferencefromotherhydroacousticsystems.

•Checkforenvironmentalnoise,suchasothervesselsinthevicinityoranimallife.

TestingtheST90operationalfunctionality

Table of Contents3
Introduction5
Purpose6
Personnel and Location6
Referenced Documents6
Tools and Test Equipment7
Acceptance Test Summary8
Hardware and Software Registration9
Verification of Previously Tested Items10
Software Items11
Hardware Items12
Display12
Processor Unit12
Transceiver Unit13
Operating Panel14
Hull Unit15
Transducer16
Visual Inspection17
Visual Inspection of the Display17
Visual Inspection of the Processor Unit19
Visual Inspection of the Operating Panel21
Visual Inspection of the Transceiver Unit22
Visual Inspection of the Hull Unit24
Environmental Inspection of the Transceiver Unit26
Making Sure that All ST90 Cables Are Properly Connected27
Testing the St90 Operational Functionality29
Checking the Transducer Lower and Hoist Functionality29
Bridge Steps30
Sonar Room Steps32
Testing the User Interface to Verify Basic Functionality34
Checking the ST90 Operation by Means of the BITE Functionality35
Testing the Interfaces with Peripheral Devices40
Verifying the Communication with a Navigation System (GPS)40
Verifying the Communication with Speed Log42
Verifying the Communication with the Course Gyro44
Verifying the Communication with the Motion Reference Unit (MRU)46
Verifying the Installation Parameters49
Verifying Vessel Origin and Ship Dimensions49
Verifying the Installation Parameters for the Transducer51
Verifying the Installation Parameters for the Global Positioning System (GPS) Antenna52
Verifying the Installation Parameters for the Motion Reference Unit (MRU)54
Customer Acceptance Form56
Secondary Procedures57
Setting up the Operating Panel (Mk2)57
