442729/A

•Thevesselisberthed.

Neithertoolsnorinstrumentsarerequired.Forconnectionsandcommunication

parameters,seetherelevantend-userdocumentationfromthesensormanufacturer.

Context

Mostglobalpositioningsystem(GPS)receiversprovideNMEA0183datagrams

containinggeographicallatitudeandlongitudeinformation,aswellascurrentspeed

andsaileddistance.SomeGPSsystemswillalsoprovidethecurrentheading,butthis

informationisnormallytakenfromthegyro.

ThepropertiesofeachoftheavailablecommunicationportsaredenedontheI/OSetup

page.TheSensorInstallationpageallowsyourST90tocommunicatewithexternal

sensorsandsystems.Tomakesurethattheinformationfromthe"mostreliable"sensors

areusedbytheST90,usetheSensorCongurationpagetodeneadatagrampriorities.

ThecommunicationparametersdenedforNMEA0183are:

•Baudrate:4800bit/s

•Databits:8

•Parity:Even

•Stopbits:1

Someinstrumentsmayprovideotherparametersand/oroptions.Youmustalwayscheck

therelevanttechnicaldocumentationsuppliedbythemanufacturer.

Procedure

1OpentheSetupmenu.

2OntheSetupmenu,selectInstallation.

ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber

ofpagesselectedfromthemenuontheleftside.

3OntheleftsideoftheInstallationdialogbox,selectSensorInstallation.

aSelecttherelevantsensorintheInstalledSensorslist.

bMakesurethatthecorrectinstallationparametersareusedforthesensor.

4OntheleftsideoftheInstallationdialogbox,selectSensorConguration.

aSelecttherelevantsensorintheSensorlist.

bMakesurethatthecorrectparametersareusedforsensorconguration.

5ClosetheInstallationdialogboxwithoutmakinganychanges.

6Observethetopbar.

7Makesurethattheinformationfromthesensorisdisplayed.

Ifnecessary,enabletheread-outintheDisplayOptionsdialogbox.

Testingtheinterfaceswithperipheraldevices
