442729/A

•Allrelevantvesseldrawings,installationreportsand/ormeasurementresultsare

available.

•TheST90systemisturnedonandoperatesnormally.

•Thevesselisberthed.

Neithertoolsnorinstrumentsarerequired.Forconnectionsandcommunication

parameters,seetherelevantend-userdocumentationfromthesensormanufacturer.

Context

Note

ThespeedinputisessentialforST90operation.Withoutspeedinformation,theST90

willneitherbeabletopresentcorrectnavigationalinformation,norcompensatefor

vesselmovements.ThislackofcompensationwillpreventtheST90fromproviding

correctechoinformation.Ifyoudonotuseadedicatedspeedlog,butratheraGPS

system,youcanskipthistest.

Inmostcasesasuitablesensorisalreadyinstalledonthevessel.Aglobalpositioning

system(GPS)withacompatibleoutputformatcanalsobeused.

ThepropertiesofeachoftheavailablecommunicationportsaredenedontheI/OSetup

page.TheSensorInstallationpageallowsyourST90tocommunicatewithexternal

sensorsandsystems.Tomakesurethattheinformationfromthe"mostreliable"sensors

areusedbytheST90,usetheSensorCongurationpagetodeneadatagrampriorities.

ThecommunicationparametersdenedforNMEA0183are:

•Baudrate:4800bit/s

•Databits:8

•Parity:Even

•Stopbits:1

Someinstrumentsmayprovideotherparametersand/oroptions.Youmustalwayscheck

therelevanttechnicaldocumentationsuppliedbythemanufacturer.

Procedure

1OpentheSetupmenu.

2OntheSetupmenu,selectInstallation.

ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber

ofpagesselectedfromthemenuontheleftside.

3OntheleftsideoftheInstallationdialogbox,selectSensorInstallation.

aSelecttherelevantsensorintheInstalledSensorslist.

bMakesurethatthecorrectinstallationparametersareusedforthesensor.

Testingtheinterfaceswithperipheraldevices
