Simrad ST90 Harbour Acceptance Test

48
442729/A
beextractedfromthereportsprovidedbythepersonnelthatdidormeasured
uptheactualinstallation.
5ClosetheInstallationdialogboxwithoutmakinganychanges.
6Observethetopbar.
7Makesurethattheinformationfromthesensorisdisplayed.
Ifnecessary,enabletheread-outintheDisplayOptionsdialogbox.
Note
Inordertoreadthemotioncompensationvalues,theST90mustbe"pinging".As
longasthevesselisinport,youcannotexpectmajorchangesinthevalues.
8Ifpossible,useanotherinstrumenttoverifythattheinformationprovidedbythe
ST90iscorrect.
9Fillintheresulttables.
Result
PortBaudrateProtocol
XOffsetYOffsetZOffset
RotationAroundXRotationAroundYRotationAroundZ
Requirements
Results
Motioncompensationisoperational.
Thecompensatedvaluesareshown.
Dateandsignature:
SimradST90HarbourAcceptanceTest
