Simrad ST90 Harbour Acceptance Test

442729/A
53
Context
Thephysicallocationoftheglobalpositioningsystem(GPS)antennarelativetothe
transducerisrequiredtoallowtheST90toshowthecorrectnavigationalinformation
intheST90presentation.ThelocationsofthetransducerandtheGlobalPositioning
System(GPS)antennamustbereferencedtoacommonShipOrigin.
Procedure
1OpentheSetupmenu.
2OntheSetupmenu,selectInstallation.
ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber
ofpagesselectedfromthemenuontheleftside.
3OntheleftsideoftheInstallationdialogbox,selectSensorInstallation.
4SelecttherelevantsensorintheInstalledSensorslist.
5Makesurethatthecorrectoffsetvalueshavebeeninserted.
6Fillintheresulttable.
Result
Globalpositioningsystem(GPS)offsets
XOffset
YOffset
ZOffset
Requirements
Results
AlloffsetvaluesareenteredintheST90.
Allvaluesarecorrect.
Allvaluesarerecordedintherelevanttable.
Dateandsignature:
