Page 14
4 Configuration
4.1 Porthand Mounting
Although the Tillerpilot is factory preset for
Starboard side mounting, it is possible to reconfig-
ure it for mounting on the Port side of the cockpit,
to facilitate easy installation on most types of
yacht.
With the power off, hold down the NAV and
TACK keys and switch on the power. Either the
Port or Starboard LED will illuminate, depending
on the current mounting configuration. Press the
PORT key to select Port side mounting. The Port
LED only will remain illuminated to indicate selec-
tion. Confirm selection and exit to Standby Mode
by pressing NAV. (Fig 4.2)
To select Starboard mounting, repeat the above
procedure, but press the Starboard key instead of
Port.
