NAV
STBY
TACK
STBY
AUTO
460mm (18in)
90º
595mm (23 in) Pushrod at mid-stroke
1
2
/
Horizontal
PB30 8mm
PB60 105mm
PB90 135mm
38mm
Pedestal Bracket (PB)
Page 17
Fig 5.2 - Installation, cross section
Fig 5.3 - Installation , plan view
