Page 24
Accessories
Height
Tiller Brackets
Push Rod Extensions
PRE30:GY
PRE60:GY
PRE90:GY
PRE120:GY
PRE150:GY
PRE300:GY
Part No.
Length
30mm (1.18")
60mm (2.36")
90mm (3.54")
120mm (4.72")
150mm (5.90")
300mm (11.81")
TB30
TB60
TB90
TB120
Part No. Height
30mm (1.18")
60mm (2.36")
90mm (3.54")
120mm (4.72")
Length
PB30
PB60
PB90
CB1
135-240mm
(5.31-9.44")
Part No Height / Length
30mm (1.18")
60mm (2.36")
90mm (3.54")
Height
Length
Cantilever Bracket CB1
Pedestal & Cantilever Brackets
23
25
