Sindoh M611 - Replacing Friction Pad of MPT Lower Body Assy

113
3. Separate the door open shaft by removing 2 screws.
4. Separate MPT from home of the front door.
Replacing Friction Pad of MPT Lower Body Assy
1. Open the front door, and remove 2 screws.
2. Separate the harness connected to the paper detection sensor at the left.
