Service Menu
Diagnostic Menu
In this chapter you can check errors occuring in the machine, and explain the test methods
and the procedures on how to fix the problems. Most of the service modes can be selected
and used while performing POR.
Diagnostic Mode
In order to execute the diagnostic test for the machine explained in this chapter you should
enter into the diagnostic mode.
This diagnostic mode group includes the settings and operation which are used for
manufacturing the machines, and performing services.
Enter into Diagnostic Mode
1. Turn on the power of the machine.
2. Check if you are on [Status] screen.
If not [Status], press [Status] button.
3. In [Status] screen press the button
1, 0, 7, * in a row.
1. Turn on the power of the machine.
2. Check if you are on [home] screen.
If not, press [home] button.
3. Press the button 1, 0, 7, * in a row.
The diagnostic mode menu is indicated on OP Panel as the following order.
Service Mode
- General Service - Snapshot version
- SP report
- System recovery
- Watchdog disable
- Printer Service - PRT Registerration - Margin Adjust - Left Margin
- Top Margin
- Back Left Margin
