158
frame.
28. Lift up and remove the sensor(A), and then 2 screws(B).
29. Separate the harness from the drive motor.
Troubleshooting
Error Messages and Codes
Service Error Codes
When a service error code appears, generally it is not possible to restore the problem, the
error may disappear by performing POR on the printer in case the error is temporary.
(A)
(B)
