190
Interval Sensor Check
This test is used to decide whether Interval Sensor attached to ADF works normlal or not.
It indicates the follwoing upon detection of the original in ADF
Original present : "1" / Original absent: "0"
1st Scan Sensor Check
This test is used to decide whether 1st Scan Sensor attached to ADF works normlal or not.
It indicates the follwoing upon detection of the original in ADF
Original present : "1" / Original absent: "0"
Top Cover Open Check
This test is used to decide on the status of Top Cover Open attached to ADF.
It indicates the follwoing upon the top cover status.
Top cover opened : "1" / Top cover closed: "0"
Home Sensor Check
This test is used to decide whether Home Sensor attached to ADF works normlal or not.
It indicates the follwoing upon detection of CIS Flag.
CIS Flag detected : "1" / CIS Flag not detected: "0"
Feed Motor
This test is used to decide whether Feed Motor attached to ADF works normlal or not.
The following are speed settings for Feed Motor mode.
1: Forward Mono 300 Speed.
2: Forward Mono 600 Speed.
3: Forward Color 300 Speed.
4: Forward Color 600 Speed.
5: Backward Mono 300 Speed.
6: Backward Mono 600 Speed.
7: Backward Color 300 Speed.
8: Backward Color 600 Speed.
After setting, press Execute button to start to drive Feed Motor.
Transport Motor
This test is used to decide whether Transport Motor attached to ADF works normlal or not.
The following are speed settings for Feed Motor mode.
.
To Next Page
