Winding the bobbin
GB
- Place thread and spool holder onto spool pin (1).
- For smaller spools of thread place spool holder with small side
next to spool (2).
- Wind thread anticlockwise around bobbin winder tension discs
(3).
- Thread bobbin as illustrated and place on spindle (4).
- Push bobbin to right (5).
- Hold thread end (6).
- Step on foot control pedal (7).
- Cut thread (8).
- Press bobbin to left (9) and remove.
Please Note:
When the bobbin winder spindle is in "bobbin winding" position,
the machine will not sew and the hand wheel will not turn. To start
sewing, push the bobbin winder spindle to the left (sewing
position).
1
2
3
678
9
4
5
