© Jun 2020 1-2 GTJZ1412E&1414E&1412E Plus Operation Manual
PERFORMANCE PARAMETERS
Table 1-1 GTJZ1412E Specifications (continued)
MEASURE
GTJZ1412E (METRIC) 4647E (IMPERIAL)
Max. allowable manual force (indoor only)
400N 90 lbf
Max. noise 72dB
POWER PARAMETERS
Hydraulic tank capacity
15L
3.3 gal(imperial)/4 gal(US)
Hydraulic system capacity (including tank)
41L
9 gal(imperial)/10.8 gal(US)
Hydraulic system pressure
21MPa 3046 Psi
Battery specification (quantity × voltage,
capacity)
4×12V,300Ah
System voltage
24VDC
Control voltage
24VDC
ENVIRONMENTAL REQUIREMENT
Max. allowable wind speed (indoor only)
0m/s
0mph
Max. allowable altitude 1000m 3280.8ft
Allowable ambient temperature (lead-acid
batteries)
-10℃ to 40℃ 14℉ to 104℉
Allowable ambient temperature (lithium
batteries)
-20℃ to 40℃ -4℉ to 104℉
Max. allowable ambient relative humidity
90%
Storage condition
Stored at -20℃ to 50℃(-4℉ to 122℉) in a well-ventilated environ-
ment with 90% relative humidity (20℃ [68℉]), and away from rain,
sun, corrosive gas and inflammable explosive.
WEIGHT
Weight (in a no-load state) (indoor only) 3375kg
7442 lb
Table 1-2 GTJZ1414E Specifications
MEASURE
GTJZ1414E (METRIC) 4655E (IMPERIAL)
DIMENSION PARAMETERS
Max. platform height
13.8m 45ft 3in.
Max. working height
15.8m 51ft 10in.
Max. horizontal extension 0.9m 3ft
Length
2.78m 9ft
Width 1.41m 4ft 7in.
Height (stowed, rails folded)
1.96m 6ft 5in.
Height (stowed, rails up)
2.6m 8ft 6in.
Wheel base 2.22m 7ft 3in.
