GTJZ1412E&1414E&1412E Plus Operation Manual 1-1 © Jun 2020
1 PERFORMANCE PARAMETERS
Table 1-1 GTJZ1412E Specifications
MEASURE
GTJZ1412E (METRIC) 4647E (IMPERIAL)
DIMENSION PARAMETERS
Max. platform height
13.8m 45ft 3in.
Max. working height
15.8m 51ft 10in.
Max. horizontal extension 0.9m 3ft
Length
2.78m 9ft
Width 1.27m 4ft 2in.
Height (stowed, rails folded)
1.96m 6ft 5in.
Height (stowed, rails up)
2.6m 8ft 6in.
Wheel base 2.22m 7ft 3in.
Wheel span
1.1m 3.6ft
Ground clearance (pothole guards
retracted)
0.1m 4in.
Ground clearance (pothole guards
deployed)
25mm 0.98in.
Tire size (diameter × width / type)
Φ380×125mm/Solid Φ15×5 in/Solid
Platform dimension (Length × Width ×
height)
2.64×1.15×1.1m 8ft 8in.×3ft 9in.×3ft 7in.
PERFORMANCE PARAMETERS
Rated load capacity of platform 227kg
500 lb
Max. load capability of extended platform 120kg
265 lb
Max. platform occupancy(indoor only) 2 person
Drive speed (stowed)
0～4 km/h
0～2.5 mph
Drive speed (raised)
0～0.8 km/h
0～0.5 mph
Uptime (in a no-load state)
75～85 s
Downtime (in a no-load state)
55～63 s
Gradeability
25%
Max. allowable inclination
3°(Front to back)/1.5°(Left to right)
Turning radius (inside)
0m 0ft
Turning radius (outside)
2.64m 8ft 8in.
Rated load capacity of a single tire 1200kg
2646 lb
