PERFORMANCE PARAMETERS
GTJZ1412E&1414E&1412E Plus Operation Manual 1-5 © Jun 2020
Table 1-3 1412E Plus Specifications (continued)
MEASURE
1412E Plus(METRIC) 4647E Plus(IMPERIAL)
Drive speed (stowed)
0～4 km/h
0～2.5 mph
Drive speed (raised)
0～0.8 km/h
0～0.5 mph
Uptime (in a no-load state)
75～85 s
Downtime (in a no-load state)
55～63 s
Gradeability
25%
Max. allowable inclination
3°(Front to back)/1.5°(Left to right)
Turning radius (inside)
0m 0ft
Turning radius (outside)
2.64m 8ft 8in.
Rated load capacity of a single tire 1200kg
2646 lb
Max. allowable manual force (indoor only)
400N 90 lbf
Max. noise 72dB
POWER PARAMETERS
Hydraulic tank capacity
15L
3.3 gal(imperial)/4 gal(US)
Hydraulic system capacity (including tank)
41L
9 gal(imperial)/10.8 gal(US)
Hydraulic system pressure
21MPa 3046 Psi
Battery specification (quantity × voltage,
capacity)
4×12V,300Ah
System voltage
24VDC
Control voltage
24VDC
ENVIRONMENTAL REQUIREMENT
Max. allowable wind speed (indoor only)
0m/s
0mph
Max. allowable altitude 1000m 3280.8ft
Allowable ambient temperature (lead-acid
batteries)
-10℃ to 40℃ 14℉ to 104℉
Allowable ambient temperature (lithium
batteries)
-20℃ to 40℃ -4℉ to 104℉
Max. allowable ambient relative humidity
90%
Storage condition
Stored at -20℃ to 50℃(-4℉ to 122℉) in a well-ventilated environ-
ment with 90% relative humidity (20℃ [68℉]), and away from rain,
sun, corrosive gas and inflammable explosive.
WEIGHT
Weight (in a no-load state) (indoor only) 3375kg
7442 lb
NOTE:
a) The working height adds 2m (6ft 7in) of human height to platform height.
b) In different areas, hydraulic oil, engine oil, coolant, fuel and lubrication should be added in accordance with the
environmental temperature.
c) In cold weather, auxiliary devices are needed to start the machines.
