PRE-OPERATION FUNCTION TEST
TB24 Plus&26J Plus Operation Manual 6-5 © Jun 2022
12. Glow plug 24. Axle retracted in place
Note:
1. When the Overload Limit symbol appears, if the platform is overloaded, a series of functions will be restricted if
the machine is in operating position. Details are provided below.
2. When the Drive Limit symbol appears, it indicates the drive function is restricted if the machine is in operating
position.
3. When the Drive & Boom Function Allowed symbol appears, it indicates the drive and boom functions are
allowed to operate simultaneously.
UNSAFE OPERATION HAZARD
• Unless in emergency situations,
never operate the machine from
the ground controller if there are
still persons on the platform.
• Never operate the machine if any
control handle or switch that
controls the platform movement
is not returned to the OFF position
after being released.
COLLISION HAZARD
Before operating the boom, ensure
the area near or under the platform is
clear of persons or obstructions.
Preparation
1. Turn the Ground/Platform select switch at the
ground controller to ground control position.
2. Pull out the emergency stop button at the ground
controller to ON position.
3. Turn the key switch at the ground controller to ON
position.
4. Ensure the relevant indicator light on the display
should be on and no error should be present.
Horn button
Push the horn button, the horn should sound.
Engine start switch
Move the engine start switch, the engine should be
started smoothly without abnormal noise.
Note: The switch will get irresponsive after engine
startup.
Glow plug switch (if equipped)
NOTICE
Before operating the machine at low temperatures,
preheat the engine for 5min to prevent damage to the
hydraulic system.
Move and hold the engine glow plug switch 6–10s,
the engine should inhale for preheating.
Note: The electrically controlled engine can be
preheated automatically.
Emergency stop button
To Next Page
