Page 36 | 45
Figure 20: Sintrol Network Example
Wireless router (Optional):
To use a wireless network, at least one additional unit is needed. This unit is used as the communication base
station which converts physical signals into the radio network and back. The base station can also be
connected to a PC via USB, where it is then possible to run Sintrol DustLog 8 data collection software to
manage and operate the network online.
Sintrol Network products operate automatically as repeaters within the network; therefore,
repeaters are rarely needed.
