13 Technical Data
Product name:
S303, S304
Measurement objects:
Total Suspended Particles (TSP)
Measurement range:
Detection Limit 0,1 mg/m³
Maximum Range up to several g/m³, depending on conditions
Measurement principle:
Inductive Electrification
Protection category:
IP65
Power supply:
24 VDC, 80-240 VAC
Power consumption:
Up to 10 W
Output signals:
 Two dry contact Relays, max 5A@30VDC / 5A@240VAC
 Isolated 4 - 20 mA output loop
Communication interface:
 2 x Serial communication RS-485
 USB
 Radio frequency (RF) (only on RF models)
Communication protocol:
 Modbus RTU (RS-485)
 Sintrol network (USB, RF and RS-485)
Ambient Conditions
Temperature:
-40 °F to 140 °F (-40 to +60 °C)
Humidity:
Max 95 % RH (non-condensing)
Materials and Weight
Enclosure / casing:
Aluminum
Wetted parts:
Probe: Stainless steel 316L
Insulation material: Ryton R-4 (a Polyphenylene sulfide)
Weight:
3,3 lbs (1,5 kg)
Process conditions
Temperature:
Max 200 °C default, optionally up to 700 °C
Pressure:
Max 3 bar default
Wireless Communication (only for RF models)
Frequency band:
868 MHz, 15 channels
915 MHz (license free ISM band)
Transmit power:
Up to +23 dBm, user adjustable
Receiver sensitivity:
-110 dBm
Communication protocol:
Proprietary Sintrol Network protocol
Typical range (no line of sight):
868 MHz Version
Up to 1000 m in urban environment
NOTE: The RF communication range is highly effected by the
surrounding structures and other RF devices.
