SBOX-2300 / VBOX-3130 Manual
33
GPIO5 Output Enable Register – Index A0h
Bit Name R/W Defaul
t
Description
7 GPIO57_OE R/W 0 0 : GPIO57 is input
1 : GPIO57 is output
6 GPIO56_OE R/W 0 0 : GPIO56 is input
1 : GPIO56 is output
5 GPIO55_OE R/W 0 0 : GPIO55 is input
1 : GPIO55 is output
4 GPIO54_OE R/W 0 0 : GPIO54 is input
1 : GPIO54 is output
3 GPIO53_OE R/W 0 0 : GPIO53 is input
1 : GPIO53 is output
2 GPIO52_OE R/W 0 0 : GPIO52 is input
1 : GPIO52 is output
1 GPIO51_OE R/W 0 0 : GPIO51 is input
1 : GPIO51 is output
0 GPIO50_OE R/W 0 0 : GPIO50 is input
1 : GPIO50 is output
GPIO5 Output Data Register – Index A1h
Bit Name R/W Defaul
t
Description
7 GPIO57_DATA R/W 1 GPIO57 output data in output mode.
6 GPIO56_DATA R/W 1 GPIO56 output data in output mode.
5 GPIO55_DATA R/W 1 GPIO55 output data in output mode.
4 GPIO54_DATA R/W 1 GPIO54 output data in output mode.
3 GPIO53_DATA R/W 1 GPIO53 output data in output mode.
2 GPIO52_DATA R/W 1 GPIO52 output data in output mode.
1 GPIO51_DATA R/W 1 GPIO51 output data in output mode.
0 GPIO50_DATA R/W 1 GPIO50 output data in output mode.
