10
TECHNICAL SPECIFICATIONS….cont
Part number 01706 01707 01708
Model F28-20 F32-20 F32-20
Input Voltage 230v ~ 50hz 230v ~ 50hz 400v ~ 50hz
Power 750 w 1100 w 1100 w
Speed Range 280-2380 rpm 150-2450 rpm 180-2500 rpm
Number of Speeds 12 12 12
Drill Bit Size 5-20 mm 5-20 mm 5-20 mm
Max. Drilling Capacity (mild Steel) 25 mm 32 mm 32 mm
Spindle Taper MT3 MT4 MT4
Table Size 290 x 290 mm 420 x 470 mm 415 x 470 mm
Base Size 460 x 272 mm 573 x 427 mm 565 x 425 mm
Column Ø 80 mm 92 mm 92 mm
Swing 360 mm 510 mm 510 mm
Height 1600 mm 1722 mm 1730 mm
Spindle Travel 82.5 mm 120 mm 120 mm
Collar Ø 65 mm 75 mm 75 mm
Max. Distance Chuck to Table 687 mm 726 mm 735 mm
Max. Distance Chuck to Base 1177 mm 1204 mm 1205 mm
Net Weight 60 Kg 117 kg 115 kg
Gross Weight 64 Kg 122 kg 122 kg
51
PARTS LIST - 01707
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Base WD02-00329 36. Connection WD02-00354
2. Column flange WD02-00330 37. Pinion shaft WD02-00355
3. Spring washer M10 WD01-00795 38. Indicator WD01-00897
4. Bolt (M10 x 35) WD02-00331 39. Screw WD02-00356
5. Crank handle WD02-00332 40. Roll pin (5 x 25) WD01-00869
6. Bolt (M6 x 12) WD01-00905 41. Screw WD02-00357
7. Circlip WD01-00742 42. Bearing 6005 WD01-00889
8. Worm shaft WD02-00333 43. Warning label WD01-00685
9. Table support WD02-00334 44. Roll pin (6 x 18) WD01-00760
10. Worm pin WD02-00335 45. Belt tension handle WD02-00358
11. Table WD02-00336 46. Lock handle WD02-00359
12. Spring washer M20 WD02-00337 47. Circlip WD01-00816
13. Bolt (M20 x 55) WD02-00338 48. Circlip WD01-00871
14. Indicator WD01-00897 49. Adjusting shaft WD01-00872
15. Lock handle WD02-00339 50. Shaft WD02-00360
16. Angle label WD02-00340 51. Washer M12 WD01-00819
17. Worm gear WD02-00341 52. Washer M10 WD02-00361
18. Column WD02-00342 53. Nut M8 WD01-00687
19. Rack WD02-00343 54. Motor plate WD02-00362
20. Screw (M4 x 10) WD01-00783 55. Bolt (M8 x 30) WD02-00363
21. Overload WD02-00344 56. Spring washer M12 WD01-00676
22. Screw (M10 x 10) WD02-00345 57. Nut M12 WD01-00821
25. Rack collar WD02-00346 58. Motor WD02-00364
26. Screw (M6 x 12) WD01-00740 59. Grub screw (M8 x 10) WD01-00689
27. Handle knob WD02-00347 60. Motor pulley WD02-00365
28. Screw (M6 x 12) WD02-00348 61. Motor pulley key WD02-00366
29. Handle cap WD02-00349 62. Nut M10 WD01-00717
30. Screw (M8 x 20) WD01-00801 63. Belt A787 WD02-00367
31. Spring washer M8 WD01-00673 64. Microswitch WD01-00706
32. Handle WD02-00350 65. Washer M5 WD01-00881
33. Scale WD02-00351 66. Spring washer M5 WD01-00882
34. Lock handle WD02-00352 67. Nut M5 WD01-00697
35. Label WD02-00353 68. Microswitch holder WD01-00709
