PARTS LIST - 01706
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Base WD02-00284 34. Washer M8 WD01-00672
2. Column flange WD02-00285 35. Motor plate WD02-00296
3. Spring washer M10 WD01-00795 36. Spring washer M12 WD01-00676
4. Bolt (M10 x 25) WD01-00796 37. Nut M12 WD01-00821
5. Rack WD02-00286 38. Grub screw (M8 x10) WD01-00689
6. Column WD02-00287 39. Motor pulley WD02-00297
7. Grub screw (M6 x 12) WD01-00740 40. Motor WD02-00298
8. Rack collar WD02-00288 41. Nut M8 WD01-00687
9. Screw (M6 x 16) WD01-00708 42. Cam assembly WD02-00299
10. Handle cap WD02-00289 43. Washer WD02-00300
11. Screw (M8 x 20) WD01-00801 44. Protecting ring WD01-00839
12. Spring washer M8 WD01-00673 45. Speed label WD02-00301
13. Handle knob WD02-00290 46. Pulley cover WD02-00302
14. Handle WD02-00291 47. Microswitch WD01-00706
15. Label WD02-00292 48. Washer M5 WD01-00881
16. Knob WD01-00867 49. Spring washer M5 WD01-00882
17. Scale WD02-00293 50. Nut M5 WD01-00697
18. Connection WD02-00294 51. Nut M6 WD01-00710
19. Pinion shaft WD02-00295 52. Spring washer M6 WD01-00707
20. Roll pin (5 x 16) WD01-00868 53. Washer M6 WD01-00702
21. Warning label WD01-00685 54. Microswitch holder WD01-00709
22. Screw (M5 x 10) WD01-00726 55. Eccentric shaft WD02-00303
23. Spindle pulley nut (M24 x 1.5) WD01-00907 56. Centre pulley WD02-00304
24. Roll pin (5 x 25) WD01-00869 57. Bearing 6202 WD01-00771
25. Roll pin (6 x 18) WD01-00760 58. Circlip WD01-00831
26. Locking handle WD01-00870 59. Belt A550 WD02-00305
27. Belt tension handle WD01-00812 60. Knurled screw WD02-00306
28. Circlip WD01-00813 61. Circlip WD01-00704
29. Circlip WD01-00871 63. Screw (M5 x 16) WD01-00838
30. Shaft WD01-00872 64. Mains lead clamp WD01-00700
31. Adjusting shaft WD01-00873 65. Protecting ring WD01-00770
32. Washer M12 WD01-00819 66. Belt A620 WD02-00307
33. Bolt (M8 x 25) WD01-00695 67. Spindle pulley WD02-00308
13
Guarantee:
These SIP pillar drills are covered by a 12 month parts and labour warranty covering
failure due to manufacturers defects. This does not cover failure due to misuse or op-
erating the pillar drill outside the scope of this manual - any claims deemed to be out-
side the scope of the warranty may be subject to charges Including, but not limited to
parts, labour and carriage costs.
This guarantee does not cover consumables such as the chuck, belts etc.
In the unlikely event of warranty claims, contact your distributor as soon as possible.
Note: Always make sure the mains supply is of the correct voltage and the
correct fuse protection is used. In the event of replacing the fuse always
replace the fuse with the same value as the original.
Note: If an extension lead is required in order to reach the mains supply;
ensure that this too is rated for the correct voltage and fuse rating.
Note: The cross section of the extension lead should be checked so that it
is of sufficient size so as to reduce the chances of voltage drops.
ELECTRICAL CONNECTION….cont
GUARANTEE
Note: Proof of purchase will be required before any warranty can be hon-
oured.
To Next Page
