GETTING TO KNOW YOUR DRILL

01700

Ref. No. Description Ref. No. Description

1. Pulley Cover 9. Belt Tension Lock

2. Motor 10. Column Support

3. NVR On/Off Switch 11. Base

4. Chuck Guard 12. Main Drill Head

5. Chuck 13. Column

6. Feed Handle 14. Column Support Bolts

7. Table 15. Depth Stop

8. Table Support Collar

EXPLODED DRAWING - 01706
